nonplanar.xyz provides the tools to use the z axis correctly in FDM printing

Whilst a 3D printer has movement for 3 axis, x, y and z, it pretty much never uses them at the same time. Usually only x and y movements of the 3D printer nozzle are used to form the geometry of the part being 3D printed. In other words, 2D planes are stacked up to create a 3D shape, instead of creating geometry with true 3D tool paths. Using the z axis correctly can open FDM 3D printing to many more possibilities. This is what Gabriel Boutin, founder of Kupol Inc. – the company behind 3D printed bike helmets – is seeking to change with the launch of nonplanar.xyz. The startup is essentially a platform that will allow you to leverage the benefits of non planar 3D printing. It provides elongated nozzles for this purpose, as well as print-ready g-codes and tutorials on custom programming for your desktop 3D printer. So what exactly are the benefits of non planar 3D printing? We spoke to Gabriel Boutin to learn more.

3DN: Can you present yourself and your relationship with 3D printing?

I am passionate about progress and self-learning. Since I have discovered industrial design and all the possibilities around software tools, I kept on pushing my own limits to become a better creator. I started my journey as an entrepreneur in 2007 by offering services to companies in Canada. I have been involved in the development of many bicycle helmets and it made me realize that it was about time for this industry to be reinvented. I had an epiphany during the summer of 2016 regarding 3D printing and its unique ability to create complex structures susceptible of absorbing energy. I immediately formulated a method for creating a helmet and I registered for an international patent. I tried my chance on Kickstarter during the summer of 2018 but I missed the target. I had to think further about the keys of success to make it happen. I moved to Montreal and I have assembled a team of four highly skilled companies to enter the NFL helmet challenge at the end of 2019. We intend to win this challenge in 2021 by presenting a fully 3D printed flexible liner that will exceed the performance of all helmets available today.

3DN: Why did you decide to create nonplanar.xyz?

Nonplanar.xyz came out of the process of looking for the right manufacturing process that will allow 3D printing to become an affordable solution for the masses. To be honest, I have disregarded FDM for many years, thinking it did not have the capability of producing high quality finished products. I was wrong. For years, we were satisfied with the typical layers produced by the variety of lookalike slicers without realizing that the z-axis was unexploited. It was simply a matter of pushing the predefined limits to produce the desired result. Nonplanar.xyz is my way of sharing what I have discovered and to make it accessible to all makers.
