Researchers create bio-inspired flexible armor using 3D printing

Nature has a way of designing structures that is often optimal. This is the reason why a number of research teams around the world are developing bio-inspired designs. At Virginia Polytechnic Institute and State University, research led by Ling Li is looking at how to make armor that is strong yet flexible, similarly to a mollusk’s shell. Typically, man-made armors often rely on rigid mechanical structures, which unsurprisingly reduce its maneuverability considerably. Using 3D printing technologies, the researchers were able to study the species’ scaled armor to create a synthetic flexible scaled armor analogue.

The researchers specifically studied chitons. This species possesses hundreds of small, mineralized scales arrayed on the soft girdle that surrounds their overlapping shell plates. Professor Ling Li explains: “Most mollusks have a single rigid shell, such as the abalone, or two shells, such as clams. But the chiton has eight mineralized plates covering the top of the creature and around its base, it has a girdle of very small scales assembled like fish scales, that provide flexibility as well as protection.” Studying the chitons’ armor meant using parametric computational modeling and multimaterial 3D printing.

For the bio-inspired flexible armor the researchers studied the chiton’s plates | Image via Virginia Tech.

This is not the first application where 3D printing is beneficial for biomimicry. Since the technology enables a new level of design freedom, it is possible to achieve designs that were simply not possible using traditional methods. In this case, the team developed a parametric 3D modeling methodology to mimic the geometry of individual scales.
